Solis 6kw ip66 Hybrid Solar Inverter with 9600W Solar Capacity Dual output
₨ 325,000
Out of stock
Out of stock
This product is currently sold out.
No worries! Enter your email, and we'll let you know as soon as it's back in stock.
Key Features:
| Input DC (PV side) | |
| Recommended max. PV power | 9.6 kW |
| Max. input voltage | 600 V |
| Rated voltage | 330 V |
| Start-up voltage | 90 V |
| MPPT voltage range | 90-520 V |
| Max. input current | 16 A / 16 A |
| Max. short circuit current | 24 A / 24 A |
| MPPT number/Max. input strings number | 2/2 |
| Battery | |
| Battery type | Li-ion / Lead-acid |
| Battery voltage range | 40-60 V |
| Max. charge / discharge power | 6 kW |
| Max. charge / discharge current | 135 A |
| Communication | CAN/RS485 |
| Output AC (Grid side) | |
| Rated output power | 6 kW |
| Max. apparent output power | 6.6 kVA |
| Operation phase | 1/N/PE |
| Rated grid voltage | 220 V / 230 V |
| Rated grid frequency | 50 Hz |
| Rated grid output current | 27.3 A / 26.1 A |
| Max. output current | 30 A |
| Power factor | >0.99 (0.8 leading – 0.8 lagging) |
| THDi | <2% |
| Input AC (Grid side) | |
| Input voltage range | 187-253 V |
| Max. input current | 40 A |
| Frequency range | 45-55 Hz / 55-65 Hz |
| Output AC (Back-up) | |
| Rated output power | 6 kW |
| Max. apparent output power | 2 times of rated power, 10 s |
| Back-up switch time | <4 ms |
| Rated output voltage | 1/N/PE, 220 V / 230 V |
| Rated frequency | 50 Hz |
| Rated output current | 27.3 A / 26.1 A |
| Max. output current | 30 A |
| Max. AC Passthrough current | 40 A |
| THDv (@linear load) | <2% |
| Efficiency | |
| Max. efficiency | > 96.9% |
| EU efficiency | > 96.5% |
| Protection | |
| DC reverse-polarity protection | Yes |
| Ground fault monitoring | Yes |
| Integrated AFCI (DC arc-fault circuit protection) | Yes (1) |
| Protection class/Over voltage category | I/II (PV and BAT), III (MAINS and BACKUP and GEN) |
| General Data | |
| Dimensions (W*H*D) | 406*560*205 mm |
| Weight | 24 kg |
| Topology | High frequency isolation (for battery) |
| Operating ambient temperature range | -40 ~ +60°C |
| Ingress protection | IP66 |
| Cooling concept | Natural convection |
| Max. operation altitude | 4000 m |
| Grid connection standard | NRS 097-2-1, IEC 62116, IEC 61727, IEC 60068, IEC 61683, EN 50530, MEA, PEA |
| Safety/EMC standard | IEC/EN 62109-1/-2, EN 61000-6-2/-3 |
| Features | |
| DC connection | MC4 plug (PV port) / Terminal Block (BAT port) |
| AC connection | Terminal Block |
| Display | LED + APP |
| Communication | RS485, CAN, Optional: Wi-Fi, GPRS, LAN |
| (1) Activation required. |
Ready to ship in 1 business day from Pakistan
Vendor Information
- Store Name: EM Store
- Vendor: EM Store
- No ratings found yet!
Eligibility:
Items can be returned or exchanged within 3 days of the purchase date.
Conditions:
Products must be unused, undamaged, and in their original packaging.
Exclusions (Non-returnable/Non-exchangeable):
Items with missing parts
Wrong product received
Defective or non-functional items
Ready to ship in 1 business day from Pakistan
Vendor Information
- Store Name: EM Store
- Vendor: EM Store
- No ratings found yet!
Eligibility:
Items can be returned or exchanged within 3 days of the purchase date.
Conditions:
Products must be unused, undamaged, and in their original packaging.
Exclusions (Non-returnable/Non-exchangeable):
Items with missing parts
Wrong product received
Defective or non-functional items
Ready to ship in 1 business day from Pakistan
Vendor Information
- Store Name: EM Store
- Vendor: EM Store
- No ratings found yet!
Eligibility:
Items can be returned or exchanged within 3 days of the purchase date.
Conditions:
Products must be unused, undamaged, and in their original packaging.
Exclusions (Non-returnable/Non-exchangeable):
Items with missing parts
Wrong product received
Defective or non-functional items
Description
- Generator connectivity with multiple input methods and automatic generator On/Off control
- Automatic UPS switching 10 second 200% surge power backup overload capability
- Supports 1ph and 3ph flexible connection with max 36kW in parallel
- Up to 135A max charge/discharge current 6 customizable charge/discharge time settings
- Compatible with lead-acid and lithium batteries, with multiple battery protection features
- Supports peak shaving control in both “self-use” and “generator” mode
