The CNC YCB7H-63A AC Circuit Breaker is a reliable and high-performance solution for protecting your electrical systems in Pakistan. This single-pole miniature circuit breaker is designed for efficient protection against overloads and short circuits. It comes in a wide range of variants, making it perfect for household boards, offices, shops, and industrial setups in cities like Karachi, Lahore, and Islamabad. With a robust design and a variety of tripping curves, this MCB provides superior performance and peace of mind.
Specifications:
- Model: YCB7H-63A
- Poles: 1 Pole
- Rated Current (In): 2A, 4A, 6A, 10A, 16A, 20A, 32A, 40A, 50A, 63A
- Rated Voltage (Ue): 230/400 V
- Rated Frequency: 50/60 Hz
- Rated Breaking Capacity: 6000 A (6.0 kA)
- Thermo-Magnetic Release Characteristic: B, C, D
- Electrical Life: 6,000 cycles
- Mechanical Life: 20,000 cycles
- Protection Degree: IP20
- Ambient Temperature: -25°C to +70°C
- Installation: 35mm DIN Rail
- Certifications: CE, CB, EAC, INMETRO
Why Choose This Product?
This AC 1 Pole MCB is an excellent choice due to its superior safety features and adaptability for the Pakistani market. Its robust design and high breaking capacity ensure reliable protection against common electrical issues. The wide range of available current ratings means you can find the perfect fit for any application, from a simple home circuit to a complex industrial setup. Its certifications and high-quality build ensure a long-lasting and dependable solution.
